Hewlett Packard Enterprise - HPE ProLiant DL20 Gen10 Plus High Performance
Server - rack-mountable - 1U - 1-way - 1 x Xeon E-2336 / 2.9 GHz - RAM 32 GB - SATA - hot-swap 2.5" bay(s) - SSD 2 x 480 GB - Matrox G200 - GigE - no OS - monitor: none
Hewlett Packard Enterprise
P63678-B21
N/A
0190017669106
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | HPE ProLiant DL20 Gen10 Plus High Performance - rack-mountable - Xeon E-2336 2.9 GHz - 32 GB - SSD 2 x 480 GB |
| Type | Server - rack-mountable |
| Height (Rack Units) | 1U |
| Localization | Region: North America |
| Server Scalability | 1-way |
| Processor | 1 x Intel Xeon E-2336 / 2.9 GHz (, up to 4.8 GHz, (6-core) |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| Cache Memory | 12 MB L3 cache |
| Cache Per Processor | 12 MB |
| RAM | 32 GB (installed) / 128 GB (max) - DDR4 SDRAM - ECC |
| Storage Controller | SATA (SATA 6Gb/s) (Intel VROC SATA Software RAID) |
| Server Storage Bays | Hot-swap 2.5" |
| Hard Drive | 2 x SSD 480 GB - SATA 6Gb/s |
| Optical Storage | No optical drive |
| Graphics Controller | Matrox G200 |
| Networking | GigE |
| Power | (50/60 Hz) |
| Power Redundancy | Yes |
| OS Provided | No operating system |
| Software Included | HPE Intelligent Provisioning, HPE iLO Management |
| Dimensions (WxDxH) | 17.1 in x 15 in x 1.7 in |
| Weight | 22.05 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | Limited warranty - parts and labor - 3 years - on-site - response time: next business day |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Built-in Devices | LED panel |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability | 1-way |
| Hot-Swap Bays Qty | 4 |
| Localization | Region: North America |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x external 5.25" ¦ 4 (total) / 2 (free) x hot-swap 2.5" SFF |
| Slots | 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - low-profile (x8 mode) |
| Interfaces | 1 x VGA ¦ 1 x HPE iLO - Type A (1 front) (service port) ¦ 1 x HPE iLO - RJ-45 (1 rear) (management port) ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x LAN (Gigabit Ethernet) / HPE iLO ¦ 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site - response time: next business day |
| Miscellaneous | |
| Included Accessories | HPE Short Friction Rail kit, 3 non-hot plug non-redundant fans |
| Compliant Standards | AES, FIPS 140-2, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.3, SMBIOS 3.2, UEFI 2.6 |
| RAM | |
| Installed Size | 32 GB / 128 GB (max) |
| Technology | DDR4 SDRAM - ECC |
| Effective Memory Speed | 3200 MHz |
| Rated Memory Speed | 3200 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 2 (empty) |
| Features | Unbuffered, dual channel memory architecture |
| Configuration Features | 2 x 16 GB |
| Networking | |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM5720 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Remote Management Controller | Integrated Lights-Out 5 |
| Features | Wake on LAN (WoL), PXE support |
| Power | |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 100-120/200-240 V (50/60 Hz) |
| Power Provided | 500 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Efficiency | 94% |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 90% (non-condensing) |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Storage Controller Name | Intel VROC SATA Software RAID |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Cache Memory | |
| Installed Size | L3 cache - 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Matrox G200 |
| Video Interfaces | VGA |
| Operating System / Software | |
| OS Provided | No operating system |
| Software | HPE Intelligent Provisioning, HPE iLO Management |
| Hard Drive | |
| Type | SSD |
| Capacity | 2 x 480 GB |
| Interface Type | SATA 6Gb/s |
| Dimensions & Weight | |
| Width | 17.1 in |
| Depth | 15 in |
| Height | 1.7 in |
| Weight | 22.05 lbs |
| Processor / Chipset | |
| CPU | Intel Xeon E-2336 |
| Clock Speed | 2.9 GHz |
| Max Turbo Speed | 4.8 GHz |
| Number of Cores | 6-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| Chipset Type | Intel C256 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
