Hewlett Packard Enterprise - HPE Aruba AP-503H (US) Unified Hospitality
Wireless access point - Wi-Fi 6 - 2.4 GHz, 5 GHz - BTO
Hewlett Packard Enterprise
R3V38A
N/A
0190017395623
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | HPE Aruba AP-503H (US) Unified Hospitality - wireless access point - Wi-Fi 6 |
| Device Type | Wireless access point |
| Form Factor | External - indoor |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 287 Mbps ¦ VPN throughput (IPSec): 100 Mbps |
| Capacity | Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 |
| Power Over Ethernet (PoE) Supported | PoE Class 3 |
| Pricing Type | BTO |
| Dimensions (WxDxH) | 3.4 in x 1.9 in x 5.9 in |
| Weight | 12.7 oz |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Indoor |
| Width | 3.4 in |
| Depth | 1.9 in |
| Height | 5.9 in |
| Weight | 12.7 oz |
| Expansion / Connectivity | |
| Interfaces | 2 x 1000Base-T - RJ-45 ¦ 1 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x console - micro-USB |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Compliant Standards | FCC, EN 60601-1-2, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, RED 2014/53/EU, IEC/EN 62368-1, IEC/EN 60950 |
| Pricing Type | BTO |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1.5 Gbps |
| Line Coding Format | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, 1024 QAM |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
| Spread Spectrum Method | OFDM, DSSS, OFDMA |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 287 Mbps ¦ VPN throughput (IPSec): 100 Mbps |
| Capacity | Wireless clients per Wi-Fi radio: 256 ¦ BSSIDs per radio: 16 |
| Status Indicators | Port status, power, system, status, PoE |
| Features | Auto-uplink (auto MDI/MDI-X), DFS support, Wi-Fi Multimedia (WMM) support, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), cyclic shift diversity (CSD), packet aggregation A-MPDU, packet aggregation A-MSDU, High-Throughput (HT) support, 2x2 MIMO technology, Very High Throughput (VHT) support, WMM Power Save, High Efficiency (HE) support, Target Wait Time (TWT), HPE SmartRate, Advanced IoT Coexistence (AIC) |
| Encryption Algorithm | WPA, WPA2, WPA3-Enterprise, Opportunistic Wireless Encryption (OWE), Simultaneous Authentication of Equals (SAE) |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11ax |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE Class 3 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 93% (non-condensing) |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 4.4 in |
| Shipping Depth | 2.1 in |
| Shipping Height | 6.6 in |
| Shipping Weight | 15.87 oz |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 2 |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE), Zigbee |
