Tripp Lite - Eaton Tripp Lite Series MTP/MPO (APC) Singlemode Slim Trunk Cable, 24-Strand, 40/100 GbE, 40/100GBASE-PLR4, Plenum, 6mm Dual Jacket, 15 m (49 ft.)
Trunk cable - MTP/MPO single-mode (F) to MTP/MPO single-mode (F) - 15 m - fiber optic - 8.3 / 125 micron - plenum, stranded - yellow
Tripp Lite
N392-15M-3X8-AP
N/A
0037332205452
N/A
New
Product Description
The N392-15M-3X8-AP MTP/MPO (APC) Single mode Slim Trunk Cable (3xF/3xF) supports 40/100 Gb Ethernet speeds and is designed for high-density connections between network equipment in telecommunication rooms and data centers. With three female MTP/MPO connectors on each end, this single mode fiber optic cable is recommended for high-density fiber patching between data center MDFs (main distribution frames) and IDFs (intermediate distribution frames).
The factory-terminated 8-fiber MTP/MPO connectors are about the same size as SC connectors, but are 12 times denser, freeing up rack space for other cables. The APC connectors are angled to prevent infrared light entering the fiber from bouncing back into the laser. Optimized for QSFP+ 40GBASE-PLR4 and QSFP28 100GBASE-PSM4 networks, this cable is tested for low insertion loss and back reflection on every connector and attenuation loss that meets or exceeds current standards.
The N392-15M-3X8-AP is colored yellow for instant identification in a crowded switch or patch panel as a single mode cable. Push/pull tab connectors are easily accessible in high-density data center applications and make the plug-and-play cable easy to install and remove with one hand. The 6-millimeter dual plenum-rated jacket and bend-insensitive fiber are perfect for connecting high-speed network components in ceilings, walls and ducts.
Efficient connector design
The cable features MTP/MPO single-mode connectors with a push-pull mechanism, promoting easy connection and disconnection in networking environments.
Robust environmental tolerance
This trunk cable operates effectively in a wide range of temperatures, from -20°C to 60°C, ensuring reliable performance under varying conditions.
Plenum-rated construction
The plenum rating of the cable makes it suitable for installation in air-handling spaces while meeting safety regulations.
High bandwidth capability
Designed to support both 40 GbE and 100 GbE applications, this cable enables efficient data transfer for modern networking needs.
Effective signal integrity
The Angled Physical Contact (APC) connectors enhance signal integrity, reducing loss and ensuring optimal performance for fiber optic connections.
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series MTP/MPO (APC) Singlemode Slim Trunk Cable, 24-Strand, 40/100 GbE, 40/100GBASE-PLR4, Plenum, 6mm Dual Jacket, 15 m (49 ft.) - trunk cable - 15 m - yellow |
| Type | Trunk cable |
| Technology | Fiber optic |
| Type of Fiber Optics | Singlemode |
| Features | Plenum, stranded, push-pull connector, Angled Physical Contact (APC) |
| Length | 15 m |
| Core / Cladding Diameter | 8.3 / 125 micron |
| Connector | 3 x MTP/MPO single-mode - female |
| Connector (Second End) | 3 x MTP/MPO single-mode - female |
| Color | Yellow |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Network Cable Type | Trunk cable |
| Technology | Fiber optic |
| Type of Fiber Optics | Singlemode |
| Fiber Qty | 8 |
| Core / Cladding Diameter | 8.3 / 125 micron |
| Features | Plenum, stranded, push-pull connector, Angled Physical Contact (APC) |
| Length | 15 m |
| Color | Yellow |
| Manufacturer Warranty | |
| Service & Support | Limited lifetime warranty |
| Miscellaneous | |
| Compliant Standards | RoHS |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 140 °F |
| Connectivity | |
| Connector | 3 x MTP/MPO single-mode - female |
| Connector (Second End) | 3 x MTP/MPO single-mode - female |
