Elo Touch Solutions - Elo Touchmonitors 0700L AccuTouch
LED monitor - 7" - portable - touchscreen - 800 x 480 - 160 cd/m² - 500:1 - 25 ms - USB - black - for Touchcomputer 15E2
Elo Touch Solutions
E791658
N/A
7411493259814
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Elo Touchmonitors 0700L AccuTouch - LED monitor - 7" |
| Device Type | LED-backlit LCD monitor - 7" - touchscreen |
| Features | Touchscreen |
| Aspect Ratio | 16:9 |
| Native Resolution | 800 x 480 |
| Pixel Pitch | 0.192 mm |
| Brightness | 160 cd/m² |
| Contrast Ratio | 500:1 |
| Response Time | 25 ms |
| Color Support | 16.7 million colors |
| Input Connectors | USB |
| Voltage | DC 5 V |
| Color | Black |
| Dimensions (WxDxH) - without stand | 7.4 in x 1.2 in x 5 in |
| Weight | 1.3 lbs |
| Compliant Standards | UL, VCCI, C-Tick, cUL, NOM, CB, IC, FCC, RoHS, WEEE, IP54 |
| Manufacturer Warranty | 3-year warranty |
| Designed For | Touchcomputer 15E2 |
| General | |
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Diagonal Size | 7" |
| Aspect Ratio | 16:9 |
| Native Resolution | 800 x 480 |
| Pixel Pitch | 0.192 mm |
| Brightness | 160 cd/m² |
| Contrast Ratio | 500:1 |
| Color Support | 16.7 million colors |
| Response Time | 25 ms |
| Vertical Refresh Rate | 60 Hz |
| Horizontal Refresh Rate | 30 kHz |
| Horizontal Viewing Angle | 140 |
| Vertical Viewing Angle | 100 |
| Backlight Technology | LED backlight |
| Features | Anti-glare, USB bus powered |
| Color | Black |
| Dimensions (WxDxH) | 7.4 in x 1.2 in x 5 in - without stand |
| Weight | 1.3 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Features | AccuTouch Five-Wire Resistive Touch technology |
| Cables Included | 1 x USB cable |
| MTBF | 50,000 hour(s) |
| Compliant Standards | UL, VCCI, C-Tick, cUL, NOM, CB, IC, FCC, RoHS, WEEE, IP54 |
| Power | |
| Input Voltage | DC 5 V |
| Power Consumption (Typical) | 4.5 Watt |
| Power Consumption Stand by / Sleep | 2.59 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Connectivity | |
| Interfaces | USB |
| Compatibility Information | |
| Designed For | Elo Touchcomputer 15E2 |
| Input | |
| Type | Touchscreen - touchscreen |
| Mechanical | |
| VESA Mounting Interface | 75 x 75 mm |
